3 Wheel Electric Forklift Truck
Model and technical parameters
| Model | Unit | FE12S | FE15S | FE18S | FE20S |
| Power Type | - | Battery | Battery | Battery | Battery |
| Load Capacity | kg/lb. | 1200/2640 | 1500/3300 | 1800/3960 | 2000/4400 |
| Load Center | mm/in. | 500/19.7 | 500/19.7 | 500/19.7 | 500/19.7 |
| Max.Lift Height | mm/in. | 3300/ 130.02 | 3300/ 130.02 | 3300/ 130.02 | 3300/ 130.02 |
| Fork Size(L*W*T) | mm/in. | 920x100 x35/ 36.25x3.94 x1.38 | 920x100 x35/ 36.25x3.94 x1.38 | 920x100 x35/ 36.25x3.94 x1.38 | 1070x122 x40/ 42.16x4.81 x1.58 |
| Tilt Angle (Fwd/Bwd) | deg | 5 / 6 | 5 / 6 | 5 / 6 | 5 / 6 |
| Length to Fork Face | mm/in. | 1830/72.10 | 1830/72.10 | 1940/76.45 | 2040/80.38 |
| Overall Width | mm/in. | 1070/42.16 | 1070/42.16 | 1070/42.16 | 1070/42.16 |
| Mast Lowered Height | mm/in. | 2135/84.12 | 2135/84.12 | 2135/84.12 | 2135/84.12 |
| Overhead Guard Height | mm/in. | 1990/78.41 | 1990/78.41 | 1990/78.41 | 1990/78.41 |
| Min.Right Angle Aisle Width | mm/in. | 3095/121.94 | 3095/121.94 | 3205/126.28 | 3305/130.22 |
| Turning Radius (outside) | mm/in. | 1400/55.16 | 1400/55.16 | 1510/59.49 | 1610/63.43 |
| Wheelbase | mm/in. | 1250/49.25 | 1250/49.25 | 1395/54.96 | 1460/57.52 |
| Ground Clearance: Mast | mm/in. | 100/3.90 | 100/3.90 | 100/3.90 | 100/3.90 |
| Travel Speed | km/h | 14.5/16.5 | 14.5/16.5 | 14.5/16.5 | 14.5/16.5 |
| Weight (with battery) | kg/lb. | 3100/6820 | 3280/7216 | 3485/7667 | 3750/8250 |
| Driving Motor | kw | 6.5x2 | 6.5x2 | 65.5x2 | 65.5x2 |
| Lifting Motor | kw | 12 | 12 | 12 | 12 |
| Battery: voltage/ capacity | V/Ah | 48/460 | 48/460 | 48/460 | 48/560 |
| Battery Weight | kg/lb. | 800/1760 | 800/1760 | 800/1760 | 1000/2200 |
| Type of Drive Contorl | - | SME | SME | SME | SME |
| Transmission Case | - | PMP | PMP | PMP | PMP |
